40K - 400KPa High Pressure Pneumatic Conveyor Blower For Wastewater Treatment Plant

  • 1
  • 2

Brand Name : Frezer

Certification : CE, ISO9001, ISO14001

Place of Origin : China

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C,T/T,Western Union

Supply Ability : 3,000 Units/Month

Delivery Time : 5-8 work days

Packaging Details : Packed in Wooden Cases

Product Name : High Pressure Pneumatic Conveying Blower

Place Of Origin : China

Delivery Methods : By Air, Sea, Land, Express

Factory Production Capacity : 3,000 Units/Month

Production Time : Shipment within 7 days after payment receipt

Pressure : 40KPa-400KPa

Package : Wooden Case

Contact Now

High Pressure Pneumatic Conveying Blower for Wastewater Treatment Plant

Product Introduction

This disassembled diagram depicts a precise mechanism merging a high-speed PMSM and hydraulic system, distinctly illustrating key elements' makeup and interaction. Stator and Rotor comprise the motor assembly. The stator generates a rotating flux to drive the rotor, realizing conversion from electrical to mechanical power. Featuring Air bearings utilizing gas lubrication to eliminate contact. Integrated with Thrust and Radial bearings for radial loading, it slashes friction, secures stable high-speed rotation, and attains 96%-98% efficiency.

40K - 400KPa High Pressure Pneumatic Conveyor Blower For Wastewater Treatment Plant

Product Specification

Details ST10 ST20 ST30 ST50 ST75 ST100 ST125 ST150 ST200 ST250 ST300 ST350 ST400 ST500 ST600 Cooling Method
Type SINGLE GRADE DOUBLE GRADE
Discharge Pressure(KPA) Air Flow(M3/MIN):LATM/20℃,65%Relative Humidity, Density=1.2KG/M3/Tolerance Air Cooling
40 10 18
60 7.5 15 20 34 51 69 82 105 140 175 210 280 345 420
70 13 18 30 45 60 74 90 120 150 180 240 300 360
80 12 17 28 42 54 70 84 109 135 164 218 270 328
90 37 50 61 71 92 140 184
100 34 45 55 67 87 133 230 260
150 32 48 60 69 81 121 125
200 56 65 71 85 Water Cooling
300 105 79
350 20 37 72
400 25 65
Motor Power(KW) 7.5 15 22 37 55 75 90 110 150 185 220 250 300 375 450
Discharge Pipe(KW) 80 100 150 150 200 200 200 200 200 200 200 200 200 200 200
Size(MM) Width 800 800 800 800 1000 1000 1000 1000 1000 1000 1200 1300 1300 1300 1300
Length 1250 1250 1250 1250 1620 1620 1620 1620 1620 1620 2200 2700 2700 2700 2700
Height 970 970 970 970 1525 1525 1525 1525 1525 1525 1916 2115 2115 2115 2115
Weight 680 680 680 750 800 960 960 1050 1050 1100 1320 1580 1580 1800 1800

Product Show

40K - 400KPa High Pressure Pneumatic Conveyor Blower For Wastewater Treatment Plant

40K - 400KPa High Pressure Pneumatic Conveyor Blower For Wastewater Treatment Plant

Products Advantages

  • High-efficiency & energy-saving design with average electricity savings exceeding 30%—Saves >30% electricity compared to traditional Roots blowers
  • Fully Enclosed Casing, Low Noise & Vibration-Free—Noise levels <80 dB, zero vibration, Eliminates the need for foundations or anchor bolts
  • IOT Smart Control & Efficient Air Energy Management—Intuitive touchscreen with 5 operating modes and 5-layer protection for intelligent, user-friendly operation
  • Oil-Free & Maintenance-Free, Semi-Permanent Lifespan—Advanced magnetic bearing technology ensures 20+ years of service with no efficiency degradation over time
  • Compact & Easy Installation—Highly integrated design, Compact, lightweight, and portable for flexible deployment

Our Service

  • Professional Team
  • Reliable Technology
  • 24 Hours Service

FAQ

Q1: What factors will you need to match the products?

Pressure & Flow Volume

Q2: What is the production time?

Normally one week after receiving your payment.

Q3: What is your minimum order quantity?

MOQ 1 set.

Q4: Are you a manufacturer?

Yes.

Q5: Which delivery methods can you support?

By air, sea, land, rail, express like DHL, UPS, FEDEX.
