Holistic Assembly Wastewater Aeration Blower for Chemical Powder Handling Plant
Product Introduction
Shown here is the cross-sectional view of the product, comprising several key components. The stator and rotor constitute the system’s main body, with an air bearing permitting seamless rotation between them. A thrust bearing is integrated to bear axial loads. The assembly additionally includes an impeller joined to the rotor, collaborating with the volute to direct fluid flow. The design focuses on efficiency, the air bearing aiding in reducing friction and wear.
Product Specification
| Details | ST10 | ST20 | ST30 | ST50 | ST75 | ST100 | ST125 | ST150 | ST200 | ST250 | ST300 | ST350 | ST400 | ST500 | ST600 | Cooling Method |
| Type | SINGLE GRADE | | DOUBLE GRADE | |
| Discharge Pressure(KPA) | Air Flow(M3/MIN):LATM/20℃,65%Relative Humidity, Density=1.2KG/M3/Tolerance | Air Cooling |
| 40 | 10 | 18 | | | | | | | | | | | | | |
| 60 | 7.5 | 15 | 20 | 34 | 51 | 69 | 82 | 105 | 140 | 175 | 210 | | 280 | 345 | 420 |
| 70 | | 13 | 18 | 30 | 45 | 60 | 74 | 90 | 120 | 150 | 180 | | 240 | 300 | 360 |
| 80 | | 12 | 17 | 28 | 42 | 54 | 70 | 84 | 109 | 135 | 164 | | 218 | 270 | 328 |
| 90 | | | | | 37 | 50 | 61 | 71 | 92 | | 140 | | 184 | | |
| 100 | | | | | 34 | 45 | 55 | 67 | 87 | | 133 | | | 230 | 260 |
| 150 | | | | | | 32 | 48 | 60 | 69 | 81 | 121 | 125 | | | |
| 200 | | | | | | | | 56 | 65 | 71 | | 85 | | | | Water Cooling |
| 300 | | | | | | | | | | | 105 | 79 | | | |
| 350 | | | | | | 20 | | | 37 | | | 72 | | | |
| 400 | | | | | | | | | 25 | | | 65 | | | |
| Motor Power(KW) | 7.5 | 15 | 22 | 37 | 55 | 75 | 90 | 110 | 150 | 185 | 220 | 250 | 300 | 375 | 450 | |
| Discharge Pipe(KW) | 80 | 100 | 150 | 150 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 |
| Size(MM) | Width | 800 | 800 | 800 | 800 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1200 | 1300 | 1300 | 1300 | 1300 |
| Length | 1250 | 1250 | 1250 | 1250 | 1620 | 1620 | 1620 | 1620 | 1620 | 1620 | 2200 | 2700 | 2700 | 2700 | 2700 |
| Height | 970 | 970 | 970 | 970 | 1525 | 1525 | 1525 | 1525 | 1525 | 1525 | 1916 | 2115 | 2115 | 2115 | 2115 |
| Weight | 680 | 680 | 680 | 750 | 800 | 960 | 960 | 1050 | 1050 | 1100 | 1320 | 1580 | 1580 | 1800 | 1800 |
Product Show
Payment Methods
T/T,L/C,West Union,Alibaba Trade Insurance,AliPay
Our History
Our company was founded in 2007, in the next 3 years we had gone to Korea to learn the high technology to develop our products. In 2013, our products have been widely used in Chinese market to save cost, increase efficiency, and decrease noise. To match the market all over the world, we have developed the high pressure products which are more than 4000KPA with more than 30 patent technologies from 2020. Nowadays, according to products updates in quality and convenience, our products are increasingly accepted by more and more customers.
Transaction Process
- Get requirements to match products
- Compare with the Roots blower
- Quotation
- Receive payment
- Production
- Packing in wooden cases
- Delivery
- Feedback
FAQ
Q1: What factors will you need to match the products?
Pressure & Flow Volume
Q2: What is the production time?
Normally one week after receiving your payment.
Q3: What is your minimum order quantity?
MOQ 1 set.
Q4: Are you a manufacturer?
Yes.
Q5: Which delivery methods can you support?
By air, sea, land, rail, express like DHL, UPS, FEDEX.
